INVENSOM-8MM EVK

INVENSOM-8MM EVK 2GB LPDDR4 RAM 16 GB eMMC Wi-Fi / Bluetooth

Inventron’s new i.MX8M Mini based System-on-Module (SOM) is an ultra compact embedded micro-computer for applications that requires security, connectivity and high performance including multimedia, virtualization, AI and machine learning.

Features of our module:

  • Multicore Hybrid Processor

§ 4x Cortex-A53 core platforms up to 1.8GHz per core

§ 1x Cortex-M4 core up to 400MHz

  • Up to 16 GB LPDDR4 RAM
  • Up to 64 GB eMMC
  • Graphics

§ 3D/2D Vivante GPU (1x shader, OpenGL® ES 2.0)

§ 1080p60 VP9 Profile 0, 2 (10-bit) decoder, HEVC/H.265 decoder, AVC/H.264 Baseline, Main, High decoder, VP8 decoder

§ 1080p60 AVC/H.264 encoder, VP8 encoder

§ MIPI DSI (4-lane), LVDS and HDMI display interface support

  • 2.4GHz & 5 GHz Dual Band Wi-Fi® 11a/b/g/n/ac 433Mbps
  • Bluetooth v5.1 BR/EDR/LE
  • ARM TrustZone, Secure Boot (HAB)
  • Audio: 5XSAI 8XPDM
  • Display: MIPI DSI (4-lane)
  • Camera: MIPI CSI (4-lane)
  • 2x USB OTG
  • 1x PCIe
  • 1x Gigabit Ethernet
  • Linux, Android, FreeRTOS support

§ Open Source Board Support Package (Linux 6.1, Android 10-13 and Ubuntu/Debian)



12972.17₺
